Description

Phantom Six Leaflet

Phantom Six Manual

Three Phase Two Quadrant DC Power Controller
  • 380/525V Three Phase AC Supply
  • 440/600V, 40 – 1500A DC Output
  • Internal P I D control
Features

The Phantom 6 is a three phase 2 quadrant converter designed to provide high performance variable speed control of DC motors.

The Phantom 6 is characterised by its system orientation, diagnostic features, ease of maintenance, compact size and advanced technology.

Major Features
  • Adaptive current control
  • 3 term PID speed control with phase advance
  • Link selection of armature or tachometer feedback
  • LED indication of 6 normal conditions
  • LED indication of 8 fault conditions
  • Comprehensive remote signalling

The Phantom 6 control cards are available as a rack system enabling us to interface to a customers existing thyristor based rectifier stack.

For further information on this controller please contact us or download any information available above.
